CLASSIC PCIe 3.0 SSD
Feature
- Timeless classic
- Customized stable firmware for storage safety
- Specially chosen Flash IC for focusing creation
- Greatly shorten your waiting time
- Built-in high-rate LDPC ECC functionality
Introduction
Timeless classic
With a classic style, the T-CREATE CLASSIC PCIe SSD targets creative talents who need to manage multiple tasks at work. A real eye-catching classic with excellent design and performance.
Customized stable firmware for storage safety
It combines a highly reliable controller on the market with customized stable firmware to create the best highly-stable SSD, taking care of your precious work.
Specially chosen Flash IC for a focus on creation
It uses well-chosen 3D TLC flash(3K P/E Cycle) that has passed strict tests to provide the best work environment so that you can focus on creation without any worries.
Greatly shorten your waiting time
It combines an ultra-fast M.2 PCIe Gen3x4 interface that offers peak read/write speed of 2700/2100 MB per second, shortening your wait and convert time and improve work efficiency.
Built-in high-rate LDPC ECC functionality
It supports high-rate LDPC (Low Density Parity Check) ECC functionality that ensures data safety and integrity in your work
5-year warranty quality assurance
The T-CREATE CLASSIC PCIe SSD offers a 5-year warranty and 1.5-million-hour MTBF. With excellent quality, it is the best companion for creators at work.
More Product Specifications
Interface
PCIe Gen3x4 with NVMe
Voltage
DC +3.3V
Operation Temperature
0˚C ~ 70˚C
Storage Temperature
-40˚C ~ 85˚C
IOPS
1TB Read/Write: 220K/200K IOPS Max
2TB Read/Write: 220K/200K IOPS Max
2TB Read/Write: 220K/200K IOPS Max
Weight
11g
Dimensions
80.0(L) x 22.0(W) x 3.7(H)mm
Humidity
RH 90% under 40°C (operational)
Vibration
80Hz~2000Hz/20G
Shock
1500G/0.5ms
MTBF
1,500,000 Hours
Operating System
System Requirements:
- Windows 11 / 10 / 8 / 7
- Linux 2.6.33 or later
Warranty
5-year limited warranty
Notes
- 1GB=1,000,000,000 Bytes. In OS system, it would be displayed as 1,000,000,000 Bytes/1024/1024/1024 = 0.93GB
- Definition and conditions of TBW (Terabytes Written)are based on JEDEC standard.
- Transmission speed will vary according to different hardware/software conditions, therefore the data can only use for basic reference.
- All the test data is provided by TEAMGROUP's laboratory and the information of test data is only for reference.We reserve the right to modify product specifications without prior notice.
- M.2 SSD Installation Instructions
